This 2.3-inch TFT display features a crisp resolution of 320x240 pixels, a wide 12H optimal viewing angle, and a bright 250 cd/m² LED backlight. Despite its compact size, this transmissive LCD operates efficiently on a low 2.8V voltage supply, ensuring seamless electrical integration. Designed to eliminate connection challenges, it provides stable and effortless operation, making it an ideal choice for Arduino, C8051, and similar projects.
Powered by the high-performance ILI9342 controller, this TFT LCD display delivers exceptional reliability and functionality. The controller enhances the display's capabilities, enabling smooth operation and precise rendering of images and graphics for a superior visual experience. Additionally, the display is RoHS compliant, meeting rigorous environmental and safety standards, reflecting a commitment to sustainability and user protection. Combining compact design, robust performance, and eco-friendly construction, this TFT display is a versatile solution for a wide range of electronic applications.
Key Features:
Perfect for: Industrial controls, medical devices, portable electronics, and more!
Learn more about this versatile LCD module and elevate your display solutions today!
| Item | Standard Value | Unit |
| Display Size | 2.3 inch | Inch |
| Number of Pixels | 320(H)x3(RGB)x 240(V) | dots |
| Active Area | 46.75(H)x 35.06(V) | mm |
| Outline Dimension | 51.00(H) x 45.80(V)x 2.50(D) <TFT> | mm |
| Viewing Direction | 12 O'clock | - |
| TFT Interface | 8080 MCU 8/16-Bit | - |
| TFT Driver IC | ILI9342 | - |
| TFT Driver Condition | VCI=2.8V,IOVCC=1.8V(Typ) | V |
| Backlight | White LED/4 PCS/4 LEDs parallel | - |
| Touch Panel | Without TP With RTP With CTP | - |
| CTP Driver IC | - - - | - |
| CTP Driver Condition | VDD=3.3V(Typ) | V |
| Operation Temperature | -20 ～ 70 | ℃ |
| Storage Temperature | -30 ～ 80 |
℃ |
